Chapter 36 OAM
GS2210 Series User’s Guide
325
Test Click Test to begin the test.
Remote
Loopback Mode
Port Enter the number of the port from which the Switch sends loopback control PDUs to initiate
or terminate a remote-loopack test.
Start Click Start to initiate a remote-loopback test from the specified port by sending Enable
Loopback Control PDUs to the remote device.
Stop Click Stop to terminate a remote-loopback test from the specified port by sending Disable
Loopback Control PDUs to the remote device.
Table 157 Advanced Application > OAM > OAM Remote Loopback (continued)
LABEL DESCRIPTION
