Chapter 3 Hardware Panels
GS2210 Series User’s Guide
32
ALM Red On A hardware failure is detected.
Off The system is functioning normally.
LOCATOR Blue Blinking Shows the actual location of the Switch between several devices in a rack.
Ethernet Ports and PoE
1-8 (GS2210-8/
8HP)
1-24 (GS2210-
24/24HP) and
1-48 (GS2210-
48/48HP)
LNK/ACT
Green Blinking The system is transmitting/receiving to/from a 10 Mbps or a 1000 Mbps
Ethernet network.
On The link to a 10 Mbps or a 1000 Mbps Ethernet network is up.
Amber Blinking The system is transmitting/receiving to/from a 100 Mbps Ethernet
network.
On The link to a 100 Mbps Ethernet network is up.
Off The link to an Ethernet network is down.
PoE
(GS2210-8HP,
GS2210-24HP
and GS2210-
48HP only)
Green On Power supplied to all PoE Ethernet ports meets the IEEE 802.3at
standard.
Amber On Power supplied to all PoE Ethernet ports meets the IEEE 802.3af standard.
Off There is no power supplied.
Mini-GBIC Slots
9-10 (GS2210-
8/8HP0
25-28
(GS2210-24/
24HP)
45-50
(GS2210-48/
48HP)
SFP
Green On The uplink port is linking at 1000 Mbps.
Blinking The system activity is transmitting/receiving data 1000 Mbps.
Amber On The uplink port is linking at 100 Mbps.
Blinking The system activity is transmitting/receiving data 100 Mbps.
Off There is no link or port, the uplink port is shut down.
Table 4 LED Descriptions (continued)
LED COLOR STATUS DESCRIPTION
