![Zyxel XS3900-48F [179/332] Mvr overview](/views2/1168992/page179/bgb3.png)
Chapter 22 Multicast
XS3900-48F User’s Guide
179
The following table describes the labels in this screen.
22.6 MVR Overview
Multicast VLAN Registration (MVR) is designed for applications (such as Media-on-Demand (MoD))
that use multicast traffic across an Ethernet ring-based service provider network.
MVR allows one single multicast VLAN to be shared among different subscriber VLANs on the
network. While isolated in different subscriber VLANs, connected devices can subscribe to and
unsubscribe from the multicast stream in the multicast VLAN. This improves bandwidth utilization
with reduced multicast traffic in the subscriber VLANs and simplifies multicast group management.
MVR only responds to IGMP join and leave control messages from multicast groups that are
configured under MVR. Join and leave reports from other multicast groups are managed by IGMP
snooping.
Table 70 Advanced Application > Multicast > Multicast Setting > IGMP Filtering Profile
LABEL DESCRIPTION
Profile Name Enter a descriptive name for the profile for identification purposes.
To configure additional rule(s) for a profile that you have already added, enter the profile
name and specify a different IP multicast address range.
Start Address Type the starting multicast IP address for a range of multicast IP addresses that you want
to belong to the IGMP filter profile.
End Address Type the ending multicast IP address for a range of IP addresses that you want to belong
to the IGMP filter profile.
If you want to add a single multicast IP address, enter it in both the Start Address and
End Address fields.
Add Click Add to save the profile to the Switch’s run-time memory. The Switch loses these
changes if it is turned off or loses power, so use the Save link on the top navigation panel
to save your changes to the non-volatile memory when you are done configuring.
Clear Click Clear to reset the fields to the factory defaults.
Profile Name This field displays the descriptive name of the profile.
Start Address This field displays the start of the multicast address range.
End Address This field displays the end of the multicast address range.
Delete To delete the profile(s) and all the accompanying rules, select the profile(s) that you want
to remove in the Delete Profile column, then click the Delete button.
To delete a rule(s) from a profile, select the rule(s) that you want to remove in the
Delete Rule column, then click the Delete button.
Cancel Click Cancel to clear the Delete Profile/Delete Rule check boxes.
