Zyxel XS3900-48F [68/332] Chapter 5 system status and port statistics
![Zyxel XS3900-48F [68/332] Chapter 5 system status and port statistics](/views2/1168992/page68/bg44.png)
Chapter 5 System Status and Port Statistics
XS3900-48F User’s Guide
68
Rx KB/s This field shows the transmission speed of data received on this port in kilobytes per
second.
Up Time This field shows the total amount of time the connection has been up.
Tx Packet
The following fields display detailed information about frames transmitted.
Unicast This field shows the number of good unicast frames transmitted.
Multicast This field shows the number of good multicast frames transmitted.
Broadcast This field shows the number of good broadcast frames transmitted.
Pause Pause is a flow control mechanism that notifies the sender to slow transmission if the
receiver’s buffers are (almost) full. This field shows the number of 802.3x Pause frames
transmitted.
Priority
Pause
You may use commands to request which Pause frames are stopped according to priority (0
to 7). For example, you may request the sender to stop Pause frames with priority equal to
3 and 4. This field shows the number of 802.1Qbb Pause frames transmitted.
Tagged This field shows the number of frames with VLAN tags transmitted.
Rx Packet
The following fields display detailed information about frames received.
Unicast This field shows the number of good unicast frames received.
Multicast This field shows the number of good multicast frames received.
Broadcast This field shows the number of good broadcast frames received.
Pause Pause is a flow control mechanism that notifies the sender to slow transmission if the
receiver’s buffers are (almost) full. This field shows the number of 802.3x Pause frames
received.
Priority
Pause
This field shows the number of 802.1Qbb Pause frames received.
Control This field shows the number of control frames received (including those with CRC error) but
it does not include the 802.3x Pause frames.
TX Collision
The following fields display information on collisions while transmitting.
Single This is a count of successfully transmitted frames for which transmission is inhibited by
exactly one collision.
Multiple This is a count of successfully transmitted frames for which transmission was inhibited by
more than one collision.
Excessive This is a count of frames for which transmission failed due to excessive collisions. Excessive
collision is defined as the number of maximum collisions before the retransmission count is
reset.
Late This is the number of times a late collision is detected, that is, after 512 bits of the frames
have already been transmitted.
Error Packet The following fields display detailed information about frames received that were in error.
RX CRC This field shows the number of frames received with CRC (Cyclic Redundant Check)
error(s).
Length This field shows the number of frames received with a length that was out of range.
Runt This field shows the number of frames received that were too short (shorter than 64
octets), including the ones with CRC errors.
Distribution
Table 12 Status > Port Details (continued)
LABEL DESCRIPTION
