Chapter 40 MAC Table
XS3900-48F User’s Guide
308
Transfer Click this to perform the MAC address transferring you selected in the Transfer Type
field.
Cancel Click this to begin configuring the search criteria afresh.
The Total Number of
MAC Address
This field displays the total number of MAC addresses learned on the Switch.
Index This is the incoming frame index number.
MAC Address This is the MAC address of the device from which this incoming frame came.
VID This is the VLAN group to which this frame belongs.
Port This is the port from which the above MAC address was learned.
Type This shows whether the MAC address is dynamic (learned by the Switch) or static
(manually entered in the Static MAC Forwarding screen).
Change Pages Click Previous or Next to show the previous/next screen if all status information
cannot be seen in one screen.
Table 149 Management > MAC Table (continued)
LABEL DESCRIPTION
