Chapter 3 Switch Hardware Overview
XS3900-48F User’s Guide
52
1 Connect the female end of the power cord to the module power socket.
2 Connect the other end of the cord to a power outlet.
The power modules can be disconnected from the power source individually. Use the following
procedure to disconnect the Switch from a power source.
1 Disconnect the power cord from the power outlet.
2 Disconnect the power cord from the module power socket.
3.3 Switch LEDs
The following table describes the Switch LEDs.
Table 8 Switch LEDs
LED COLOR STATUS DESCRIPTION
SYS Green Blinking The Switch is rebooting and performing self-diagnostic tests.
On The Switch is on and functioning properly.
Amber On The Switch is overheating due to abnormal voltage or fan speed.
Off The power is off or the Switch is not ready or malfunctioning.
MGMT
LINK Green On The MGMT port is connected at 1000 Mbps.
Amber On The MGMT port is connected at 10 or 100 Mbps.
Off The MGMT port is not up or not connected to an Ethernet device.
ACTIVITY Green Blinking The Switch is transmitting or receiving to/from an Ethernet device
through the MGMT port.
Off The Switch is not transmitting or receiving to/from an Ethernet
device through the MGMT port.
1-48 Green Blinking The port is receiving or transmitting data at 1 or 10 Gbps.
On The port has a successful 1 or 10 Gbps connection.
Off This link is disconnected.
49-52 Green Blinking The port is receiving or transmitting data at 40 Gbps.
On The port has a successful 40 Gbps connection.
Off This link is disconnected.
