![Zyxel XS3900-48F [316/332] Switch configuration](/views2/1168992/page316/bg13c.png)
Chapter 43 Troubleshooting
XS3900-48F User’s Guide
316
Click the Display button in the System Log field in the Management > Diagnostic screen to
check for unauthorized access to your Switch. To avoid unauthorized access, configure the secured
client setting in the Management > Access Control > Remote Management screen for telnet,
HTTP and SSH (see Section 36.6 on page 294). Computers not belonging to the secured client set
cannot get permission to access the Switch.
43.3 Switch Configuration
I lost my configuration settings after I restart the Switch.
Make sure you save your configuration into the Switch’s
nonvolatile memory each time you make changes. Click Save
at the top right corner of the web configurator to save the
configuration permanently. See also Section 35.3 on page 270 for more information about how to
save your configuration.
