![Zyxel XS3900-48F [18/332] Pfc ets and dcbx standards](/img/pdf.png)
Zyxel XS3900-48F [18/332] Pfc ets and dcbx standards
![Zyxel XS3900-48F [18/332] Pfc ets and dcbx standards](/views2/1168992/page18/bg12.png)
Chapter 1 Getting to Know Your Switch
XS3900-48F User’s Guide
18
The following table explains the acronyms in the graphic.
1.2.1 PFC, ETS, and DCBX Standards
DCB may use PFC, ETS, application priority and DCBX to adapt to the FCoE.
Table 1 DCB Graphic Key
LABEL DESCRIPTION
EES Enhanced Ethernet Switch
LLAN Legacy Local Area Network (Ethernet)
ELAN Enhanced LAN (Ethernet & FCoE)
FCF Fiber Channel Forwarder
SAN Storage Access Network
