Chapter 7 VLAN
XS3900-48F User’s Guide
87
VLAN Type Select Normal (static) or Private. For Private VLANs, select Primary, Isolated or
Community.
Association
VLAN List
Primary private VLANs can associate with several (secondary) Community private VLANs
and up to one (secondary) Isolated private VLAN.
You only configure VLAN Association List for Primary private VLANs. Use a dash to
associate consecutive VLANs and a comma (no spaces) to associate non-consecutive
VLANs. For example, 51-53 includes 51, 52 and 53, but 51,53 does not inlcude 52.
Secondary private VLANs can only be associated with one primary private VLAN.
Port The port number identifies the port you are configuring.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all ports. Use this row
first to set the common settings and then make adjustments on a port-by-port basis.
Note: Changes in this row are copied to all the ports as soon as you make them.
Control Select Normal for the port to dynamically join this VLAN group using GVRP. This is the
default selection.
Select Fixed for the port to be a permanent member of this VLAN group.
Select Forbidden if you want to prohibit the port from joining this VLAN group.
Tagging Select TX Tagging if you want the port to tag all outgoing frames transmitted with this
VLAN Group ID.
Add Click Add to save your changes to the Switch’s run-time memory. The Switch loses these
changes if it is turned off or loses power, so use the Save link on the top navigation panel to
save your changes to the non-volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Clear Click Clear to reset the fields to the factory defaults.
VID This field displays the ID number of the VLAN group. Click the number to edit the VLAN
settings.
Active This field indicates whether the VLAN settings are enabled (Yes) or disabled (No).
Name This field displays the descriptive name for this VLAN group.
VLAN Type This field displays the Normal or Private (Primary, Isolated or Community) type VLAN
configured in the top part of this screen.
Association
VLAN List
This field displays which secondary private VLANs are associated with a primary private
VLAN configured in the top part of this screen.
Delete Click Delete to remove the selected entry from the summary table.
Cancel Click Cancel to clear the Delete check boxes.
Table 22 Advanced Application > VLAN > Static VLAN (continued)
LABEL DESCRIPTION
