Chapter 24 IP Source Guard
XS3900-48F User’s Guide
202
The DHCP snooping database maintains the dynamic bindings for DHCP snooping and ARP
inspection in a file on an external TFTP server. If you set up the DHCP snooping database, the
Switch can reload the dynamic bindings from the DHCP snooping database after the Switch
restarts.
You can configure the name and location of the file on the external TFTP server. The file has the
following format:
Figure 106 DHCP Snooping Database File Format
The <initial-checksum> helps distinguish between the bindings in the latest update and the
bindings from previous updates. Each binding consists of 72 bytes, a space, and another checksum
that is used to validate the binding when it is read. If the calculated checksum is not equal to the
checksum in the file, that binding and all others after it are ignored.
24.1.2.3 DHCP Relay Option 82 Information
The Switch can add information to DHCP requests that it does not discard. This provides the DHCP
server more information about the source of the requests. The Switch can add the following
information:
• Slot ID (1 byte), port ID (1 byte), and source VLAN ID (2 bytes)
• System name (up to 32 bytes)
This information is stored in an Agent Information field in the option 82 field of the DHCP headers of
client DHCP request frames. See Chapter 34 on page 263 for more information about DHCP relay
option 82.
When the DHCP server responds, the Switch removes the information in the Agent Information field
before forwarding the response to the original source.
You can configure this setting for each source VLAN. This setting is independent of the DHCP relay
settings (Chapter 34 on page 263).
24.1.2.4 Configuring DHCP Snooping
Follow these steps to configure DHCP snooping on the Switch.
1 Enable DHCP snooping on the Switch.
2 Enable DHCP snooping on each VLAN, and configure DHCP relay option 82.
<initial-checksum>
TYPE DHCP-SNOOPING
VERSION 1
BEGIN
<binding-1> <checksum-1>
<binding-2> <checksum-1-2>
...
...
<binding-n> <checksum-1-2-..-n>
END
