Chapter 36 Access Control
XS3900-48F User’s Guide
279
fanairflow FanAirFlowEventOn 1.3.6.1.4.1.890.1.5.8.74.31.2.1 Fan module and power module fan air-
flow must be in the same direction
(front-to-back or back-to-front) on the
same Switch. This trap is sent when
the airflows are not in the same
direction.
FanAirFlowEventClear 1.3.6.1.4.1.890.1.5.8.74.31.2.2 Fan module and power module fan air-
flow must be in the same direction
(front-to-back or back-to-front) on the
same Switch. This trap is sent when
the airflows return to the same
direction.
reset UncontrolledResetEventOn 1.3.6.1.4.1.890.1.5.8.74.31.2.1 This trap is sent when the Switch
automatically resets.
ControlledResetEventOn 1.3.6.1.4.1.890.1.5.8.74.31.2.1 This trap is sent when the Switch
resets by an administrator through a
management interface.
RebootEvent 1.3.6.1.4.1.890.1.5.1.1.2 This trap is sent when the Switch
reboots by an administrator through a
management interface.
timesync RTCNotUpdatedEventOn 1.3.6.1.4.1.890.1.5.8.74.31.2.1 This trap is sent when the Switch fails
to get the time and date from a time
server.
RTCNotUpdatedEventClear 1.3.6.1.4.1.890.1.5.8.74.31.2.2 This trap is sent when the Switch gets
the time and date from a time server.
intrusionlock IntrusionLockEventOn 1.3.6.1.4.1.890.1.5.8.74.31.2.1 This trap is sent when intrusion lock
occurs on a port.
loopguard LoopguardEventOn 1.3.6.1.4.1.890.1.5.8.74.31.2.1 This trap is sent when loopguard shuts
down a port.
errdisable errdisableDetect 1.3.6.1.4.1.890.1.5.8.74.130.4.1 This trap is sent when an error is
detected on a port, such as a loop
occurs or the rate limit for specific
control packets is exceeded.
errdisableRecovery 1.3.6.1.4.1.890.1.5.8.74.130.4.2 This trap is sent when the Switch
ceases the action taken on a port, such
as shutting down the port or discarding
packets on the port, after the specified
recovery interval.
Table 130 SNMP System Traps (continued)
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
Table 131 SNMP InterfaceTraps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
linkup linkUp 1.3.6.1.6.3.1.1.5.4 This trap is sent when the Ethernet
link is up.
LinkDownEventClear 1.3.6.1.4.1.890.1.5.8.74.31.2.2 This trap is sent when the Ethernet
link is up.
linkdown linkDown 1.3.6.1.6.3.1.1.5.3 This trap is sent when the Ethernet
link is down.
LinkDownEventOn 1.3.6.1.4.1.890.1.5.8.74.31.2.1 This trap is sent when the Ethernet
link is down.
