Chapter 5 System Status and Port Statistics
XS3900-48F User’s Guide
66
5.2.1 Status: Port Details
Click a number in the Port column in the Status screen to display individual port statistics. Use this
screen to check status and detailed performance data about an individual port on the Switch.
Link This field displays the speed (1000M for 1000 Mbps, 10G for 10 Gbps, and 40G for 40
Gbps) and the duplex (F for full duplex). This field displays Down if the port is not
connected to any device.
State If STP (Spanning Tree Protocol) is enabled, this field displays the STP state of the port. (See
Section 11.1.3 on page 108 for more information).
If STP is disabled, this field displays FORWARDING if the link is up, otherwise, it displays
STOP.
LACP This fields displays whether LACP (Link Aggregation Control Protocol) has been enabled on
the port.
TxPkts This field shows the number of transmitted frames on this port.
RxPkts This field shows the number of received frames on this port.
Errors This field shows the number of received errors on this port.
Tx KB/s This field shows the transmission speed of data sent on this port in kilobytes per second.
Rx KB/s This field shows the transmission speed of data received on this port in kilobytes per
second.
Up Time This field shows the total amount of time in hours, minutes and seconds the port has been
up.
Clear Counter Type a port number, select Port and then click Clear Counter to erase the recorded
statistical information for that port, or select Any to clear statistics for all ports.
Table 11 Port Status (continued)
LABEL DESCRIPTION
