Chapter 36 Access Control
XS3900-48F User’s Guide
281
accounting RADIUSAcctNotReachableEventOn 1.3.6.1.4.1.890.1.5.8.74.31.2.1 This trap is sent when there is no
response message from the
RADIUS accounting server.
RADIUSAcctNotReachableEventClear 1.3.6.1.4.1.890.1.5.8.74.31.2.2 This trap is sent when the
RADIUS accounting server can be
reached.
Table 132 AAA Traps (continued)
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
Table 133 SNMP IP Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
ping pingProbeFailed 1.3.6.1.2.1.80.0.1 This trap is sent when a single ping probe fails.
pingTestFailed 1.3.6.1.2.1.80.0.2 This trap is sent when a ping test (consisting of a
series of ping probes) fails.
pingTestCompleted 1.3.6.1.2.1.80.0.3 This trap is sent when a ping test is completed.
traceroute traceRouteTestFailed 1.3.6.1.2.1.81.0.2 This trap is sent when a traceroute test fails.
traceRouteTestCompleted 1.3.6.1.2.1.81.0.3 This trap is sent when a traceroute test is
completed.
Table 134 SNMP Switch Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
stp STPNewRoot 1.3.6.1.2.1.17.0.1 This trap is sent when the STP root switch
changes.
MRSTPNewRoot 1.3.6.1.4.1.890.1.5.8.74.35.2.1 This trap is sent when the MRSTP root
switch changes.
MSTPNewRoot 1.3.6.1.4.1.890.1.5.8.74.107.7
0.1
This trap is sent when the MSTP root switch
changes.
STPTopologyChange 1.3.6.1.2.1.17.0.2 This trap is sent when the STP topology
changes.
MRSTPTopologyChange 1.3.6.1.4.1.890.1.5.8.74.35.2.2 This trap is sent when the MRSTP topology
changes.
MSTPTopologyChange 1.3.6.1.4.1.890.1.5.8.74.107.7
0.2
This trap is sent when the MSTP root switch
changes.
mactable MacTableFullEventOn 1.3.6.1.4.1.890.1.5.8.74.31.2.1 This trap is sent when more than 99% of
the MAC table is used.
MacTableFullEventClear 1.3.6.1.4.1.890.1.5.8.74.31.2.2 This trap is sent when less than 95% of the
MAC table is used.
rmon RmonRisingAlarm 1.3.6.1.2.1.16.0.1 This trap is sent when a variable goes over
the RMON "rising" threshold.
RmonFallingAlarm 1.3.6.1.2.1.16.0.2 This trap is sent when the variable falls
below the RMON "falling" threshold.
cfm dot1agCfmFaultAlarm 1.3.111.2.802.1.1.8.0.1 The trap is sent when the Switch detects a
connectivity fault.
