Industrial Secure Router User's Manual Firewall
8-7
PROFInet RT Unicast (UDP) 34962
PROFInet RT Multicast (TCP) 34963
PROFInet RT Multicast (UDP) 34963
PROFInet Context Manager (TCP) 34964
PROFInet Context Manager (UDP) 34964
IEC 60870-5-104 (TCP) 2404
IEC 60870-5-104 (UDP) 2404
DNP (TCP) 20000
DNP (UDP) 20000
The Quick Automation Profile also includes the commonly used Ethernet protocols listed in the following table:
Ethernet Protocol Port Number
IPSec NAT Traversal (UDP) 4500
IPSec NAT traversal (TCP) 4500
FTP-data (TCP) 20
FTP-data (UDP) 20
FTP-control (TCP)
21
FTP-control (UDP) 21
SSH (TCP) 22
SSH (UDP) 22
Telnet (TCP) 23
Telnet (UDP) 23
HTTP (TCP) 80
HTTP (UDP) 80
IPSec (TCP) 1293
IPSec (UDP) 1293
L2F & L2TP (TCP) 1701
L2F & L2TP (UDP) 1701
PPTP (TCP) 1723
PPTP (UDP) 1723
Radius authentication (TCP) 1812
Radius authentication (UDP) 1812
RADIUS accounting (TCP) 1813
RADIUS accounting (UDP) 1813
