Industrial Secure Router User's Manual Getting Started

2-3

4. Click the Terminal tab, select VT100 for Terminal Type, and then click OK to continue.

5. The Console login screen will appear. Use the keyboard to enter the login account (admin or user), and

then press Enter to jump to the Password field. Enter the console Password (the same as the Web

Browser password; leave the Password field blank if a console password has not been set), and then press

Enter.

NOTE

The default password for the EDR series with firmware v3.0 and later is “moxa”.

For previous firmware

versions, the default password is blank. For greater security, please change the default password after the first

6. Enter a question mark (?) to display the command list in the console.

The following table lists commands that can be used when the Industrial Secure Router is in console (serial or

Telnet) mode:

Command Description

quit Exit Command Line Interface

exit Exit Command Line Interface

reload Halt and Perform a Cold Restart

terminal Configure Terminal Page Length

copy

Import or Export File

save Save Running Configuration to Flash

ping Send Echo Messages

clear Clear Information

show Show System Information

configure Enter Configuration Mode

Using Telnet to Access the Industrial Secure

Router’s Console

You may use Telnet to access the Industrial Secure Router’s console utility over a network. To access the EDR’s

functions over the network (by either Telnet or a web browser) from a PC host that is connected to the same

LAN as the Industrial Secure Router, you need to make sure that the PC host and the Industrial Secure Router

are on the same logical subnet. To do this, check your PC host’s IP address and subnet mask. By default, the

LAN IP address is 192.168.127.254 and the Industrial subnet mask is 255.255.255.0 (for a Class C subnet). If

you do not change these values, and your PC host’s subnet mask is 255.255.0.0, then its IP address must have
