Industrial Secure Router User's Manual EDR-810 Series Features and Functions
3-46
SNMP Versions
Setting Description Factory Default
Disable
V1, V2c, V3, or
V1, V2c, or
V3 only
Select the SNMP protocol version used to manage the secure
router.
Disable
Auth. Type
Setting Description Factory Default
MD5 Provides authentication based on the HMAC-MD5 algorithms.
8-character passwords are the minimum requirement for
authentication.
MD5
SHA Provides authentication based on the HMAC-SHA algorithms.
8-character passwords are the minimum requirement for
authentication.
No-Auth Provides no authentication
Data Encryption Enable/Disable
Setting Description Factory Default
Enable/Disable Enable of disable the data encryption Disable
Data Encryption Key
Setting Description Factory Default
Max. 30 Characters 8-character data encryption key is the minimum requirement
for data encryption
None
Community Name
Setting Description Factory Default
Max. 30 Characters Use a community string match for authentication Public
Access Control
Setting Description Factory Default
Read/Write Access control type after matching the community string Read/Write
Read only (Public MIB
only)
No Access
Target IP Address
Setting Description Factory Default
IP Address Enter the IP address of the Trap Server used by your network. 0.0.0.0.
