Industrial Secure Router User's Manual Virtual Private Network (VPN)
9-6
See the X.509 Certification section in this chapter for details.
Encryption Algorithm
Setting Description Factory Default
DES
3DES
AES-128
AES-192
AES-256
Encryption Algorithm in key exchange 3DES
Hash Algorithm
Setting Description Factory Default
Any
MD5
SHA1
SHA256
Hash Algorithm in key exchange SHA1
DH Group
Setting Description Factory Default
DH1(modp 768)
DH2(modp 1024)
DH5(modp 1536)
DH14(modp 2048)
Diffie-Hellman groups
(the Key Exchange group between the Remote and VPN
Gateways)
DH2(modp 1024)
Negotiation Time
Setting Description Factory Default
Negotiation time The number of allowed reconnect times when startup mode is
initiated. If the number is 0, this tunnel will always try
connecting to the remote gateway when the VPN
tunnel is not
created successfully.
0
IKE Lifetime
Setting Description Factory Default
IKE lifetime (hours)
Lifetime for IKE SA
1 (hr)
Rekey Expire Time
Setting Description Factory Default
Rekey expire time
(minutes)
Start to Rekey before IKE lifetime expired 9 (min)
Rekey Fuzz Percent
Setting Description Factory Default
0-100 (%) The rekey expire time will change randomly to enhance the
security.
Rekey fuzz percent is the maximum random change margin of
the Rekey expire time.
100% means the rekey expire time will not change randomly.
100 (%)
