Industrial Secure Router User's Manual EDR-810 Series Features and Functions
3-18
If the new configuration does not block the connection from the remote user to the Industrial Secure Router,
the user will see the SettingCheck Confirmed page, shown in the following figure. Click Confirm to save the
configuration updates.
System File Update—by Remote TFTP
The Industrial Secure Router supports saving your configuration file to a remote TFTP server or local host to
allow other Industrial Secure Routers to use the same configuration at a later time, or saving the Log file for
future reference. Loading pre-saved firmware or a configuration file from the TFTP server or local host is also
supported to make it easier to upgrade or configure the Industrial Secure Router.
TFTP Server IP/Name
Setting Description Factory Default
IP Address of TFTP
Server
The IP or name of the remote TFTP server. Must be configured
before downloading or uploading files.
None
