Industrial Secure Router User's Manual Network Redundancy
6-5
Explanation of “Settings” Items
Redundancy Protocol
Setting Description Factory Default
Turbo Ring V2 Select this item to change to the Turbo Ring V2 configuration page.
None
RSTP (IEEE 802.1W/
802.1D-2004)
Select this item to change to the RSTP configuration page.
None Ring redundancy is not active
Enable Ring 1
Setting Description Factory Default
Enabled Enable the Ring 1 settings Not checked
Disabled Disable the Ring 1 settings Not checked
Enable Ring 2*
Setting Description Factory Default
Enabled Enable the Ring 2 settings
Not checked
Disabled Disable the Ring 2 settings
Note: You should enable both Ring 1 and Ring 2 when using the Dual-Ring architecture.
Set as Master
Setting Description Factory Default
Enabled Select this device as Master
Not checked
Disabled Do not select this device as Master
Redundant Ports
Setting Description Factory Default
1st Port Select any port of the device to be one of the redundant ports.
See the following table
2nd Port
Select any port of the device to be one of the redundant ports.
See the following table
Enable Ring Coupling
Setting Description Factory Default
Enable Select this EDS as Coupler
Not checked
Disable Do not select this EDS as Coupler
Coupling Mode
Setting Description Factory Default
Dual Homing Select this item to change to the Dual Homing configuration
page
See the following
table
Ring Coupling
(backup)
Select this item to change to the Ring Coupling (backup)
configuration page
See the following
table
Ring Coupling
(primary)
Select this item to change to the Ring Coupling (primary)
configuration page
See the following
table
