Industrial Secure Router User's Manual Virtual Private Network (VPN)
9-14
VPN Plan
• All communication from the Roaming user (no fixed IP) to the Remote site Network (100.100.3.0/24) needs
to pass through the VPN tunnel.
• Communication goes through the Internet.
• The configuration of the WAN/LAN interface for the Industrial Secure Router is shown in the following table.
Configuration Industrial Secure Router (1)
EDR-G903
Interface Setting
WAN IP 100.100.2.1
LAN IP 100.100.3.1
Based on the requirement and VPN plan, the recommended configuration for L2TP over IPSec is shown in the
following table:
Configuration Industrial Secure Router (1)
L2TP Server Setting L2TP Server Mode (WAN1) Enable
Local IP (L2TP Server IP) 100.100.4.1
Offer IP Range 100.100.4.1 ~100.100.4.100
Login User / Password User01 / 12345
Tunnel Setting Connection Type Site to Site (Any)
L2TP Tunnel Enable
Local Network 100.100.3.1 / 24
(Same as LAN Interface)
Startup mode Wait for Connection
Key Exchange Pre-Shared Key 12345
Data Exchange Encryption Algorithm
Harsh Algorithm
3DES
SHA1
