MS-7566 Mainboard
En-2
Mainboard Specifications
Processor Support
- Intel
®
Core i7 processors in the LGA1366 package
(For the latest information about CPU, please visit
http://global.msi.com.tw/index.php?func=cpuform2)
Supported QPI
- Up to 25.6 GB/s
Chipset
- North Bridge: Intel
®
X58 chipset
- South Bridge: Intel
®
ICH10R chipset
Memory Support
- 6 DDR3 DIMMs support DDR3 1600(OC)/ 1333/ 1066/ 800 SDRAM
(24GB Max)
- Supports 3 channels
(For more information on compatible components, please visit http:/
/global.msi.com.tw/index.php?func=testreport)
LAN
- Supports 2 PCIE LAN 10/100/1000 Fast Ethernet by Realtek
®
8111C
Audio (optional)
- Sound Blaster
®
X-Fi™ Xtreme Audio Card
- 24-bit / 96KHz audio quality
- 100dB SNR clarity
- Up to 7.1ch EAX
®
5.0 Surround Sound
SATA
- 6 SATAII ports by Intel
®
ICH10R
- 4 SATAII ports by JMicron
®
JMB322
- 2 E-SATA ports by JMicron
®
JMB362
- Supports storage and data transfers up to 3 Gb/s
RAID
- SATA1~6 support Intel
®
Martix Storage Technology (AHCI + RAID 0/
1/5/10) by Intel
®
ICH10R
- SATA7/8 support RAID 0/ 1 (hardware RAID) mode by 1st JMicron
®
JMB322
- SATA9/10 support RAID 0/ 1 (hardware RAID) mode by 2nd JMicron
®
JMB322
- Two E-SATA ports on back panel support RAID 0/ 1 & JBOD mode by
JMicron JMB362
IEEE1394 (optional)
- 2 IEEE1394 ports (rear*1, front*1) by VIA
®
VT6308
NVIDIA
®
nForce
®
200
- Supports NVIDIA
®
SLI™ Multi Graphic solution
