MS-7566 Системная плата
Ru-34
Настройка BIOS
В этой главе приводятся основные сведения о программе настройки BIOS
(BIOS SETUP), которая позволяет установить оптимальную конфигурацию
системы. Эта программа может потребоваться в следующих случаях:
* Во время загрузки системы появляется сообщение об ошибке с требованием
запустить BIOS SETUP.
* Вы желаете заменить заводские настройки на собственные.
Внимание
1.Для улучшения работы системы содержимое каждого из разделов
BIOS, рассматриваемое в данной главе, постоянно совершенствуется.
Поэтому, для новых версий BIOS оно может несколько отличаться
от данного описания, которое сможет служить в качестве ориентира.
2.При загрузке, в первой, после объема памяти строке, выводится
обозначение BIOS . Обычно оно имеет следующий формат:
A7566IMS V1.0 010109 где:
1ая буква соответствует изготовителю BIOS ( A = AMI, W = AWARD
и P = PHOENIX)
Следующие 4 цифры соответствуют номеру модели.
Следующая буква обозначает поставщика чипсета (A = AMD, I = Intel, V
= VIA, N = Nvidia, U = ULi).
2 следующие буквы обозначают заказчика MS = стандартный заказчик.
V1.0 соответствует номеру версии BIOS.
010109 - дата выпуска BIOS.
