De-15
Deutsch
Debug LED
Beziehen Sie bitte sich die auf unter Tabelle , um mehr Informationen über Debug LED
Meldung zu erhalten.
USB Port
Dieser USB (Universal Serial Bus) Anschluss zum direkten Anschluss von USB-
Geräten, wie etwa Tastatur, Maus oder weiterer USB-kompatibler Geräte.
Post Status
FF Anschalten und initialisieren zuerst CPU.
C0, C1, C2 Early CPU Initialize.
C4, C6 Frühe CPU initialisieren.
D4, D5 Initialisieren Sie Speicher.
08 Initialisieren Sie Tastatur.
2A, 31 Initialisieren Sie Geräte. Laden Sie Option ROM (VGA und RAID
Option ROM) vom BIOS zum Speicher.
37 Anzeigen die Meldung der Anmeldeverfahrens, CPU Information,
die Meldung des Rüst-Schlüssels und irgendwelche spezifischen
Informationen des Originalherstellers.
38 Initialisieren Sie USB Gerät und unterschiedlichen Geräten.
3C Mittlere POST-Initialisierung der Chipsetregister. Decken Sie
unterschiedlichen Geräte (Parallel Ports, Serial Ports und der
Coprozessor in CPU…etc.)
75, 78 Initialisieren Sie INT 13 Geräte und IPL Geräte. (Schließt SATA/
PATA HDD und CD/DVD ROM ein).
87 Anrufen Einstellung Schirm. BIOS installiert, wenn es abgefragt/
angefordert wird.
A4 Warten auf Eingabe am Konfigurierbild, wenn es angefordert
wird.
A7 Zeigt den Systemkonfiguration Schirm an, wenn es aktiviert
ist.
B1 Speichern System Kontext für ACPI (Advanced Configuration and
Power Interface). Bereitet es die Steuerung zum Betriebssystem
(INT 19H), um Programm zu laden.
00 Setzen OS ein (typischerweise INT 19H).
AA Eintragen OS (Vista oder Windows XP).
