Ru-15
Русский
Индикатор загрузки (Debug LED)
Сообщения индикатора загрузки (Debug LED) перечислены в таблице ниже.
Код Состояние
FF Включение питания и первичная инициализация CPU.
C0, C1, C2 Этапы ранней инициализации CPU.
C4, C6 Инициализация чипсета.
D4, D5 Инициализация памяти.
08 Инициализация памяти.
2A, 31 Включение интегрированных устройств. Загрузка
дополнительных ROM (VGA и RAID ROM) из BIOS в память.
37 Сообщение POST, вывод информации о CPU, сообщение
о горячих клавишах и дополнительная информация об OEM-
производителе.
38 Инициализация USB и других устройств.
3C Mid-POST инициализация регистров чипсета. Определение
различных устройств (параллельные, последовательные
порты и сопроцессоры в CPU и др.)
75, 78 Инициализация устройств INT 13 и IPL (включая жесткие
диски SATA/ PATA и CD/DVD ROM).
87 Вход в программу настройки BIOS, если необходимо/
требуется пользователю.
A4 Ожидание ввода от пользователя в экране конфигурации.
A7 Отображение экрана конфигурации, если включено.
B1 Сохранение контекста системы для ACPI (Advanced
Configuration and Power Interface). Подготовка к передаче
управления загрузчику OS (INT 19H).
00 Передача управления загрузчику OS (обычно INT 19H).
AA Загрузка OS (Vista или Windows XP).
Порт USB
USB порт (Universal Serial Bus) позволяет подключать такие USB устройства,
как клавиатура, мышь и т.д.
