![Aten VM5808H [104/118] Echo command](/views2/1211650/page104/bg68.png)
VM5404H / VM5808H User Manual
94
Echo Command
The Echo function updates the RS232 controller when operations are made via
the front panel pushbuttons, web browser, or telnet. The changes echo back to
the RS232 controller to keep the settings in sync with the device.
The formula for the Echo command is as follows:
Command + Control + [Enter]
1. For example, to enable the echo feature, type:
echo on [Enter]
The following tables show the possible values for the Echo command
:
Note: Each command string can be separated with a space.
The following table lists the available Echo commands:
Command Description
echo Echo command
Control Description
on Turns Echo function on
off Turns Echo function off (default)
Command Control Enter Description
echo on [Enter] Turn on Echo function
echo off [Enter] Turn off Echo function
