Chapter 5. RS-232 Commands
95
Black Screen Command
The Black Screen command turns a display screen black when no source signal
is detected. This prevents the display from showing the default blue or other
color used when no source signal is detected.
The formula for the Black Screen command is as follows:
Command + Control + [Enter]
1. For example, to enable the Black Screen function, type:
blackscreen on [Enter]
The following tables show the possible values for the Black Screen command
:
Note: Each command string can be separated with a space.
The following table lists the available Black Screen commands:
Command Description
blackscreen Black Screen command
Control Description
on Turns Black Screen function on
(default)
off Turns Black Screen function off
Command Control Enter Description
blackscreen on [Enter] Turn on Black Screen function
blackscreen off [Enter] Turn off Black Screen function
