Chapter 3. Front Panel Configuration
21
LCD Menu Organization
The VM5404H / VM5808H has a built-in configuration utility via the front
panel LCD, which can be controlled by pressing the MENU and front panel
Input pushbuttons (1–8) or (1–4). User can cycle through the menu options,
starting from IP Setting page, in the order shown in the table below:
Note: The highlighted values are the default settings of the VM5404H /
VM5808H.
Menu Page Sub-Menu Page(s)
IP Setting IP Address
Subnet Mask
Gateway
Serial Port Setting Baud Rate 9600 / 19200 / 38400 / 115200
Operation Mode EDID Default / Port1 / Remix / Customized
CEC On / NA
OSD On / NA
Output Status Video On / NA
Output
Resolution
01-04 (VM5404H);
01-08 (VM5808H)
Security Mode Mode None
Password Enable
Lock Screen
Change Password Old Password New Password
Save to a Profile Save to a Profile No. 01–08 (VM5404H); 01-16 (VM5808H)
Play/Stop the Profile Schedule
Turn Video Wall Off
