Chapter 5. RS-232 Commands
97
Baud Rate Command
The Baud Rate command allows you to set the RS-232 data rate for the
VM5404H / VM5808H to use. Options are 9600, 19200 (default) 38400 and
115200.
The formula for the Baud Rate command is as follows:
Command + Control + [Enter]
1. For example, to set 38400 as the baud rate, type:
baud 38400 [Enter]
The following tables show the possible values for the Baud Rate command:
Note: Each command string can be separated with a space.
The following table lists the available Baud Rate commands:
Command Description
baud Sets the RS-232 baud rate
Control Description
9600 Use 9600 baud rate
19200 Use 19200 baud rate (default)
38400 Use 38400 baud rate
115200 Use 115200 baud rate
Command Control Enter Description
baud 9600 / 19200 / 38400 /
115200
[Enter] Sets the RS-232 baud
rate
