VM5404H / VM5808H User Manual
iv
Package Contents
The VM5404H / VM5808H package consists of:
1 VM5404H / VM5808H HDMI Matrix Switch with Scaler
1Power Cord
1 IR Remote Control
1 IR Receiver
1 Mounting Kit
1 User Instructions*
Check to make sure that all the components are present and that nothing got
damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit, and/or any of the
devices connected to it.
* Features may have been added to the VM5404H / VM5808H since this
manual was published. Please visit our website to download the most up-to-
date version.
© Copyright 2016 ATEN® International Co., Ltd.
Manual Date: 2016-06-27
VM5404H Firmware Version: V1.0.076
VM5808H Firmware Version: V1.3.126
ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
