Aten VM5808H [46/118] Power on off all output displays

VM5404H / VM5808H User Manual

Power on/off all Output displays

To power on/off all Output displays simultaneously, with the remote control,

do the following:

1. Press the ON or OFF pushbutton.*

2. Repeat step 1 to simultaneously change back the power status of all Output

ports, to on or off, respectively.

*The ON or OFF pushbuttons bring all displays to the same power status,

regardless of the individual power statuses.
