VM5404H / VM5808H User Manual
100
Alert Command
To trigger a warning when issues arise for a specific input port, use the
following command:
Command + Input + Number + Control + [Enter]
1. For example, to enable the basic Alert function for input port 1, type:
alert i01 m1 [enter]
The following tables show the possible values for the Alert command:
Note: Each command string can be separated with a space.
The following table lists the available Alert commands:
Command Description
alert Alert command
Input Description
i Input command
Port number Description
yy 01-08 port
Control Description
off Disable Alert (default)
m1 Show basic Alert (flashing border)
m2 Show detailed Alert (flashing border
and port information)
Command
Input
Command
Input Port
Control Enter Description
alert
iyy
off [Enter] Alert off for input port yy
(yy:01~08)
alert
iyy
m1 [Enter] Basic Alert on for input port yy
(yy:01~08)
alert
iyy
m2 [Enter] Detailed Alert on for input port yy
(yy:01~08)
