VM5404H / VM5808H User Manual
96
Read Command
The Read command allows you to view the current configuration, firmware
and other information about the device.
The formula for the Read command is as follows:
Command + [Enter]
1. To view information about the device, type:
read [Enter]
The following table shows the possible values for the Read command:
Note: Each command string can be separated with a space.
The following table lists the available Read commands:
Reset Command
The Reset command allows you to reset the VM5404H / VM5808H to the
default factory settings.
The formula for the Reset command is as follows:
Command + [Enter]
The following tables show the possible values for the Reset command:
Note: Each command string can be separated with a space.
The following table lists the available Reset commands:
Command Description
read Read command
Command Enter Description
read [Enter] View information about the
device
Command Description
reset Reset command
Command Enter Description
reset [Enter] Resets the device settings
