Aten VM5808H [95/118] Edid mode command
![Aten VM5808H [95/118] Edid mode command](/views2/1211650/page95/bg5f.png)
Chapter 5. RS-232 Commands
85
EDID Mode Command
Extended Display Identification Data (EDID) is a data that contains a display's
basic information and is used to communicate with the video source.
The formula for the EDID command is as follows:
Command + Control + [Enter]
1. For example, to use the Port1 EDID mode, type:
edid port1 [enter]
The following tables show the possible values for the EDID command:
Note: Each command string can be separated with a space.
The following table lists the available EDID commands:
Command Description
edid EDID Mode command
Control Description
port1 Implement the EDID of the connected
display to Port 1, and pass it to the
video source.
remix Implement the EDID of each
connected display according to its
connection when the VM5404H /
VM5808H is first powered on, or
immediately after selecting the Remix
option.
default Implements ATEN’s default EDID.
(default)
custom Implements the customized mode as
set in the EDID system settings.
(See Customized EDID Settings,
page 68)
Command Control Enter Description
edid port1 [Enter] The EDID from Port 1 is passed to the video
source.
edid remix [Enter] The VM5404H / VM5808H implements the
EDID of each connected display according to
its connection when the VM5404H / VM5808H
is first powered on, or immediately after
selecting the Remix option.
edid default [Enter] ATEN’s default EDID is passed to the video
source.
