Aten VM5808H [89/118] Ro read what output is connected to nn input

Chapter 4. Browser Operation

8. RO – Read what output is connected to nn input

RO 01

Output port 02 is connected to input port 01

9. SB – Set serial port baud rate

SB 96

Serial port baud rate is set to 9600

10. SS – Switch input to specified output

SS 01,03

Switch input 01 to output 03

11. SV – Save the current connections into a profile

SV 01

Save the current connections into profile 01

12. TI – Set timeout

TI 30

Set 30 minute timeout

13. VR – Software version information

Software version 1.0.

Note: For further information about these functions, please reference the

equivalent Browser GUI functions earlier in this chapter.
