VM5404H / VM5808H User Manual
2
Features
Connects up to 4 (VM5404H) or 8 (VM5808H) HDMI sources to any of 4/
8 HDMI displays
Long Distance Transmission – supports up to 15 m (24 AWG)
HDMI (3D, Deep color); HDCP 1.4 compatible
Video wall – allows you to create custom video wall layouts via intuitive
web GUI
Features a built-in high-performance scaler function for best image quality
Seamless Switch – ATEN FPGA design unifies video formats to provide
continuous video streaming, real-time switching and stable signal
transmissions*
EDID Expert – selects optimum EDID settings for smooth power-up and
high quality display
Multiple Control Methods – system management via front-panel
pushbuttons, IR, RS-232 and Ethernet (Telnet / Web GUI) connections
Built-in bi-directional RS-232 serial port for high-end system control
Superior video quality – HDTV resolution of 480p, 720p, 1080i and 1080p
(1920 x 1080)
Supports Dolby True HD and DTS HD Master audio
Consumer Electronics Control (CEC) support
ESD protection for HDMI connections
Firmware upgradeable
Rack mountable all metal casing
Note: If Seamless Switching is enabled, the video output will not display
3D, Deep Color or interlace resolution (i.e., 1080i). For these
features, you must disable Seamless Switching.
