![Aten VM5808H [93/118] Switch port command](/views2/1211650/page93/bg5d.png)
Chapter 5. RS-232 Commands
83
Switch Port Command
The Switch Port command allows you to switch ports on the VM5404H /
VM5808H.
The formula for the Switch command is as follows:
Command + Input + Number + Output + Number + Control + [Enter]
1. For example, to switch input port 02 to output port 05, type:
sw i02 o05 [Enter]
2. To switch output port 04 to the next port, type:
sw o04 + [Enter]
3. To turn off video output on port 03, type:
sw o03 off [Enter]
The following tables show the possible values for the Switch Port command:
Command Description
sw Switch command
Input Command Description
i Input command
Port number Description
xx 01-08 port
Output Command Description
o Output command
Port number Description
yy 01-08 port
* All output ports
Control Description
on Turn on the display
off Turn off the display
+Next Port
-Previous Port
