- 11 -
Hardware Installation
USB Chipset+ASMedia
®
USB 3.1 Gen 2 Controller:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 1xUSB3.1Gen2Type-Aport(red)onthebackpanel
Chipset:
- 10 x USB 3.1 Gen 1 ports (6 ports on the back panel, 4 ports available through
the internal USB headers)
- 2 x USB 2.0/1.1 ports on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x VGA_PW power connector
1 x CPU fan header
1 x water cooling CPU fan header
4 x system fan headers
1 x system fan/water cooling pump header
1 x 3 Amp fan/water cooling pump header
1 x digital LED strip header
1 x digital LED strip power select jumper
2 x RGB (RGBW) LED strip headers
1 x M.2 Socket 3 connector
8 x SATA 6Gb/s connectors
1 x Intel
®
VROC Upgrade Key header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x USB 3.1 Gen 1 headers
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
1 x Thunderbolt
™
add-in card connector
1 x power button
1 x reset button
1 x Clear CMOS button
2 x temperature sensor headers
Back Panel
Connectors
2 x USB 2.0/1.1 ports
6 x USB 3.1 Gen 1 ports
1 x USB Type-C
™
port, with USB 3.1 Gen 2 support
1 x USB 3.1 Gen 2 Type-A port (red)
2 x RJ-45 ports
1 x optical S/PDIF Out connector
5 x audio jacks
I/O Controller
iTE
®
I/O Controller Chip
