Recovering your system with Smart Backup:

Steps:

1. Click the System Recovery button on the main menu.

2. Select the location where your backup is saved.

3. Use the time slider to select a time point.

4. Select a partition backup created on the selected time point and

click Restore.

5. Conrmwhethertorestartyoursystemtoproceedwiththerestore

immediately or later. Once you respond "Yes" the system will restart to

the Windows recovery environment. Follow the onscreen instructions

to restore your system.

Allofyourlesandprogramswillbedeletedandreplacedwith

those on the selected backup. If needed, be sure to make a

copy of your data before the restore.
