- 10 -
Hardware Installation
1-2 ProductSpecications
CPU Support for Intel
®
Core
™
X series processors (6-core or above) in the LGA2066
package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
X299 Express Chipset
Memory Intel
®
Core
™
X series 48-lane processors:
- 8 x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM
capacity) of system memory
Intel
®
Core
™
X series 44-lane/28-lane processors:
- 8 x DDR4 DIMM sockets supporting up to 128 GB (16 GB single DIMM
capacity) of system memory
4 channel memory architecture
Support for DDR4 4000(O.C.)/3866(O.C.)/3800(O.C.)/3733(O.C.)/
3666(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/
3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz memory modules
Support for non-ECC Un-buffered DIMM
Support for Extreme Memory Profile (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek
®
ALC1220-VB codec
* The back panel line out jack supports DSD audio.
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN 2 x Intel
®
GbE LAN chips (10/100/1000 Mbit)
Expansion Slots 4 x PCI Express x16 slots, running at x16 (PCIEX16_1/2/3/4)
3 x PCI Express x16 slots, running at x8 (PCIEX8_1/2/3)
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
* Refer to "1-6 Setting up AMD CrossFire
™
/NVIDIA
®
SLI
™
Configuration," for the
installation notices for the PCI Express x16 slots.
Multi-Graphics
Technology
Support for NVIDIA
®
Quad-GPU SLI
™
and 4-Way/3-Way/2-Way NVIDIA
®
SLI
™
technologies
Support for AMD Quad-GPU CrossFire
™
and 4-Way/3-Way/2-Way AMD
CrossFire
™
technologies
Storage Interface Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe
x4/x2 SSD support)
- 8 x SATA 6Gb/s connectors
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
* The M.2 connector supports SATA RAID only.
*
Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
Intel
®
Optane
™
Memory Ready
