Gigabyte X299-WU8 (rev. 1.0) [123/136] Enabling stereo mix

- 123 -

Appendix

Step 1:

Locate the icon in the notification area and right-click

on this icon. Select Recording devices.

* Enabling Stereo Mix

If the HD Audio Manager does not display the recording device you wish to use, refer to the steps below. The

followingstepsexplainhowtoenableStereoMix(whichmaybeneededwhenyouwanttorecordsoundfrom

yourcomputer).

Step 2:

On the Recording tab, right-click on Stereo Mix item and

select Enable.Thensetitasthedefaultdevice.(ifyoudo

not see Stereo Mix, right-click on an empty space and

select Show Disabled Devices.)

Step 3:

Now you can access the HD Audio Manager to configure

Stereo Mix and use Voice Recorder to record the sound.
