Gigabyte X299-WU8 (rev. 1.0) [36/136] Vroc upgrade key header

- 36 -

20) BAT (Battery)

 Thebatteryprovidespowertokeepthevalues(suchasBIOScongurations,date,andtimeinformation)

intheCMOSwhenthecomputeristurnedoff.Replacethebatterywhenthebatteryvoltagedropstoalow

level, or the CMOS values may not be accurate or may be lost.

You may clear the CMOS values by removing the battery:

1. Turn off your computer and unplug the power cord.

• Replacethebatterywithanequivalentone.Damagetoyourdevicesmayoccurifthebatteryis

replaced with an incorrect model.

• Contact the place of purchase or local dealer if you are not able to replace the battery by yourself

or uncertain about the battery model.

• Wheninstallingthebattery,notetheorientationofthepositiveside(+)andthenegativeside(-)

ofthebattery(thepositivesideshouldfaceup).

• Used batteries must be handled in accordance with local environmental regulations.

21) VROC (Intel

This header can be used to connected an Intel
