- 25 -
Hardware Installation
1-9 Internal Connectors
Readthefollowingguidelinesbeforeconnectingexternaldevices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X4_1/ATX_12V_2X4_2
2) ATX
3) VGA_PW
4) CPU_FAN
5) SYS_FAN1/2/3/4
6) SYS_FAN5_PUMP
7) CPU_OPT
8) HPWR_FAN_PUMP
9) EC_TEMP1/EC_TEMP2
10) D_LED
11) DLED_V_SW
12) LED_C1/LED_C2
13) SATA3 0/1/2/3/4/5/6/7
14) M2P
15) F_PANEL
16) F_AUDIO
17) SPDIF_O
18) F_USB30_1/F_USB30_2
19) TPM
20) BAT
21) VROC
22) THB_C
23) CLR_CMOS
