- 30 -
Hardware Installation
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
For how to turn on/off the lights of the LED strip, refer to the instructions in Chapter 5, "Unique
Features,""APPCenter\RGBFusion."
F_USB30
F_U
B_
F_ F_
_
B
BS_
B
SB_
B
_S
S_
_
B
_U
_
B
S
123
123
123
123
1
1
1
1
BSS
S
_S
SSU
1 2 3
S3
BSSS
U
__ 3
F_USB3F
S _
S _
S _
SF
B_
B_
F
_0
S
S
_0F
_F
_
_
__B
U
S _S
_
SF_
USB0_B
B_
F_USB3
_
_3U
1
11) DLED_V_SW (Digital LED Strip Power Select Jumper)
This jumper allows you to select the supply voltage of the D_LED header. Be sure to verify the voltage
requirements of your digital LED strip and set the correct voltage with this jumper before connection.
Incorrect connection may lead to the damage of the LED strip.
1
1
1-2:5V(Default)
2-3: 12V
10) D_LED (Digital LED Strip Header)
The header can be used to connect a standard 5050 digital LED strip, with maximum power rating of 2A
(12Vor5V)andmaximumlengthof5mormaximumnumberof300LEDs.Thereare12Vand5Vdigital
LED strips. Be sure to verify the voltage requirements of your digital LED strip and set the DLED_V_SW
jumper accordingly.
Connect your digital LED strip to the header. There are 12V and 5V
digital LED strips. Be sure to verify the voltage requirements of your
digital LED strip and set the DLED_V_SW jumper. The power pin
(markedwithatriangleontheplug)oftheLEDstripmustbeconnected
to Pin 1 of the digital LED strip header. Incorrect connection may lead
to the damage of the LED strip.
Digital LED
Strip
1
Pin No. Denition
1 V
2 D
3 No Pin
4 G
