- 13 -

Hardware Installation

Bundled

Software

 Norton

Internet Security (OEM version)

 cFosSpeed

 XSplit Gamecaster + Broadcaster (12 months license)

Operating

System

 Support for Windows 10 64-bit

Operating

Properties

 Operating temperature: -10°C to 50°C

 Operating humidity: 8 - 90%

 Non-operating temperature: -40°C to 70°C

 Non-operating humidity: 5% - 95%

Form Factor



E-ATX Form Factor; 30.5cm x 26.7cm

* GIGABYTE reserves the right to make any changes to the product speciﬁcations and product-related information without

prior notice.

Please visit GIGABYTE's website for support lists of CPU, memory modules, SSDs, and M.2

devices.

Please visit the Support\Utility List page on GIGABYTE's website to download the latest

version of apps.
