Conguring a RAID Set

- 70 -

Figure 4

After completing, you'll be brought back to the Intel(R) Rapid Storage Technology screen. Under RAID Volumes

youcanseethenewRAIDvolume.Toseemoredetailedinformation,press<Enter>onthevolumetocheckfor

informationonRAIDlevel,stripeblocksize,arrayname,andarraycapacity,etc.(Figure4).

Figure 5

Delete RAID Volume

TodeleteaRAIDarray,press<Enter>onthevolumetobedeletedontheIntel(R) Rapid Storage Technology

screen. After entering the RAID VOLUME INFO screen, press <Enter> on Delete to enter the Delete screen.

Press <Enter> on Yes(Figure5).
