- 87 -

Conguring a RAID Set

Step 5:

Enteravolumenamewith1~16letters(letters

cannotbespecialcharacters)undertheName item

and press <Enter>. Then, select a RAID level.(The

selections available depend on the number of the

hard drives and type of the Intel

VROCUpgrade

Keybeinginstalled)

Step 6:

Under the Select Disks item, select the hard drives

tobeincludedintheRAIDarray.Pressthe<Space>

keyontheharddrivestobeselected(selectedhard

drivesaremarkedwith"X").

Step 7:

Then set the stripe block size. The stripe block

size can be set from 4 KB to 128 KB. Once you

have selected the stripe block size, set the volume

capacity. After setting the capacity, move to Create

Volume and press <Enter> to begin.

Step 8:

After completing, you'll be brought back to the

Intel(R) Virtual RAID on CPU screen. Under Intel

VROC Managed Volumes you can see the new

RAIDvolume.

Step 3:

After the system reboots, enter BIOS Setup again.

Then enter the Peripherals\Intel(R) Virtual RAID

on CPU sub-menu. Press <Enter> on All Intel VMD

Controller.

Step 4:

Press <Enter> on Create RAID Volume to enter the

Create RAID Volume screen.
