SiBE311209 Field Setting
Test Operation 150
3.1.4 Setting Contents and Code No. for Indoor Units
Note: 1. Settings are made simultaneously for the entire group, however, if you select the mode No.
inside parentheses, you can also set by each individual unit. Setting changes however
cannot be checked except in the individual mode for those in parentheses.
2. The mode numbers inside parentheses cannot be used by wireless remote controllers, so
they cannot be set individually. Setting changes also cannot be checked.
3. Marked are factory setting.
4. Do not make settings other than those described above. Nothing is displayed for functions
the indoor unit is not equipped with.
5. “
88” may be displayed to indicate the remote controller is resetting when returning to the
normal mode.
6. If the setting mode to “Equipped”, heat reclaim ventilator fan conducts the fan residual
operation by linking to indoor unit.
7. • The FXMQ50·63·80·100·125·140PVE cannot be set to 30Pa.
• The FXMQ20·25·32·40PVE cannot be set to 180 or 200Pa.
Mode
No.
(Note 2)
First
Code
No.
Setting Contents Second Code No.(Note 3)
Details
No
01 02 03 04
10(20) 0 Filter contamination heavy/
light (Setting for display time
to clean air filter) (Sets
display time to clean air filter
to half when there is heavy
filter contamination.)
Ultra long
life filter
Light Approx.
10,000
hrs.
Heavy Approx.
5,000
hrs.
——(1)
Long life
filter
Approx.
2,500
hrs.
Approx.
1,250
hrs.
Standard
filter
Approx.
200 hrs.
Approx.
100 hrs.
1 Long life filter type
Long life filter
Ultra long life filter
——(2)
2 Selection of thermistor
Room temperature
thermistor and suction
air thermistor
Suction air
thermistor
Remote
controller
thermistor
—(3)
3
Display time to clean air filter calculation (Set
when filter sign is not to be displayed.)
Display No display — — (4)
5 Information to intelligent Manager,
intelligent Touch Controller
Only unit sensor
value (or remote
sensor if
installed).
Sensor value as
set by 10-2-X or
10-6-X.
———
6 Thermostat sensor in group control
Use unit sensor
only (or remote
sensor if
installed).
Use both unit
sensor (or remote
sensor if installed)
AND remote
sensor.
———
11
(21)
7 Airflow adjustment
OFF
Completion of
airflow adjustment
Start of airflow
adjustment
—
(5)
12(22) 0 Optional accessories output selection
(field selection of output for adaptor for
wiring)
Indoor unit turned
ON by thermostat
— Operation
output
Error output (6)
1 ON/OFF input from outside (Set when
ON/OFF is to be controlled from outside.)
Forced OFF ON/OFF control External
protection
device input
—(7)
2 Thermostat differential changeover (Set
when remote sensor is to be used.)
1°C 0.5°C — — (8)
3
Airflow setting when heating thermostat is OFF
LL Set fan speed — — (9)
4 Automatic mode differential (automatic
temperature differential setting for VRV
system heat recovery series cool/heat)
01:0 02:1 03:2 04:3 05:4 06:5 07:6 08:7 (10)
5 Power failure automatic reset Not equipped
Equipped — — (11)
6
Airflow setting when Cooling thermostat is OFF
LL Set airflow — — (12)
13(23) 0 Setting of normal airflow
N H S — (13)
1 Selection of airflow direction (Set when a
blocking pad kit has been installed.)
F (4 directions) T (3 directions) W
(2 directions)
— (14)
3
Operation of downward flow flap: Yes/No
Equipped Not equipped — — (15)
4 Setting of airflow direction adjustment
range
Draft prevention
Standard Ceiling soiling
prevention
— (16)
5 Setting of static pressure selection
Standard High static
pressure
— — (17)
6 External Static Pressure Settings
01:30 02:50 03:60 04:70 05:80 06:90
07:100 08:110
(18)
09:120 10:130 11:140 12:150
13:160 14:180 15:200
∗7
15(25) 1 Thermostat OFF excess humidity
Not equipped Equipped — — (19)
2 Direct duct connection (when the indoor
unit and heat reclaim ventilator are
connected by duct directly.)
∗Note 6
Not equipped Equipped — — (20)
3
Drain pump humidifier interlock selection
Not equipped Equipped — — (21)
5 Field setting selection for individual
ventilation setting by remote controller
Not equipped Equipped — — (22)
