SiBE311209 Troubleshooting by Indication on the Remote Controller
Service Diagnosis 256
4.32 Subcooling Heat Exchanger Gas Pipe Thermistor (R5T)
Abnormality
Remote
Controller
Display
J9
Applicable
Models
Outdoor Unit: RTSQ8~16PAY1
Function Unit: BTSQ20PY1
Method of Error
Detection
Error is detected according to the temperature detected by subcooling heat exchanger gas pipe
thermistor.
Error Decision
Conditions
When the subcooling heat exchanger gas pipe thermistor is short circuited or open circuited
Supposed
Causes
Defective subcooling heat exchanger gas pipe thermistor (R5T)
Defective outdoor unit PCB
Troubleshooting
Refer to P.314.
Caution
Be sure to turn off the power switch before connecting or disconnecting
connectors, or parts may be damaged.
Is the connector for
subcooling heat
exchanger gas pipe
thermistor connected to
X30A on outdoor unit
PCB (A1P)?
NO
YES
Is the resistance measured
after removing the
thermistor (R5T) from
outdoor unit PCB
normal?
CHECK 11
NO
YES
Connect the connector and operate
the unit again.
Replace the thermistor (R5T).
Replace the outdoor unit PCB
(A1P).
CHECK 11
