SiBE311209 Specifications
Specifications 52
1.3 BS Units
Note:
+
1 When connecting with a 20 to 50 class indoor unit, connect to the attached pipe to the field pipe.
(Braze the connection between the attached and field pipe.)
+
2 When connecting with an indoor unit of 150 or more and 160 or less, connect to the attached pipe to the field pipe.
(Braze the connection between the attached and field pipe.)
Model BSV4Q100PV1 BSV6Q100PV1
Power Supply 1 Phase 50Hz 200-240V 1 Phase 50Hz 200-240V
Total capacity index of connectable indoor
units
400 or less 600 or less
Capacity index of connectable indoor units
per branch
100 or less
No. of Connectable Indoor Units Max. 20 Max. 30
Casing Galvanized steel plate Galvanized steel plate
Dimensions: (H×W×D) mm 209×1053×635 209×1577×635
Sound Absorbing Thermal Insulation
Material
Foamed polyurethane, Flame resistant needle felt Foamed polyurethane, Flame resistant needle felt
Piping
Connection
Indoor
Unit
Liquid Pipes 9.5mm C1220T (brazing connection)
+
1 9.5mm C1220T (brazing connection)
Gas Pipes 15.9mm C1220T (brazing connection)
+
1 15.9mm C1220T (brazing connection)
+
2
Outdoor
Unit
Liquid Pipes 12.7mm C1220T (brazing connection) 15.9mm C1220T (brazing connection)
Suction Gas Pipes 28.6mm C1220T (brazing connection) 28.6mm C1220T (brazing connection)
+
2
HP/LP Gas Pipes 19.1mm C1220T (brazing connection) 28.6mm C1220T (brazing connection)
+
2
Weight kg 60 89
Standard Accessories
Installation manual, Attached pipe
Insulation pipe cover, Clamps
Installation manual, Attached pipe
Insulation pipe cover, Clamps
Drawing No. 4D064131A 4D064132A
