SiBE311209 Troubleshooting by Indication on the Remote Controller
Service Diagnosis 248
4.24 Outdoor Air Thermistor (R1T) Abnormality
Remote
Controller
Display
H9
Applicable
Models
Outdoor Unit: RTSQ8~16PAY1
Method of Error
Detection
Error is detected from the temperature detected by the outdoor air thermistor.
Error Decision
Conditions
When the outdoor air temperature thermistor has short circuit or open circuit
Supposed
Causes
Defective outdoor air thermistor connection
Defective outdoor air thermistor (R1T)
Defective outdoor unit PCB (A1P)
Troubleshooting
Refer to P.314.
Caution
Be sure to turn off the power switch before connecting or disconnecting
connectors, or parts may be damaged.
Connector is
connected to X18A
of outdoor unit
PCB (A1P).
NO
YES
Resistance is normal
when measured after
disconnecting the
thermistor (R1T) from the
outdoor unit PCB.
CHECK 11
NO
YES
Connect the connector and turn ON
again.
Replace the thermistor (R1T)
Replace the outdoor unit PCB
(A1P).
CHECK 11
